Elysia xpector

Model

Elysia xpector

Portable, compact and full of features.
The qube is our ultraportable and loved chassis for professional audio wherever you need it. Our customers love the versatility and connections of the qube, so we decided to make a custom backplate for the xpector.

The in- and outputs that we needed for a dual headphone amplifier without compromises just can’t be offered by the 500 Series format. With 12 audio connections on the back panel the xpector meets every requirement – from home enthusiast to professional studios.

Get connected.
The xpector has mirrored headphone outputs for the engineer and the artist on the back. If you want to connect speakers or your studio monitors you can use the balanced XLR outputs to use the xpector as your monitor controller and benefit from the superb audio quality and true three-dimensional stereo image.

The stereo Direct and DAW inputs feed signals to the corresponding mix controllers at the front so that engineers and artists can adjust their mix to taste. But we’re not stopping. If you want to daisy-chain multiple units you can. Or use the Loop outputs to feed the output signal of a preamp connected to the direct input to your interface. There are multiple possibilities using the xpector – see the application examples below.

Puristic Power.

It all starts with a strong foundation. We designed a super-low noise internal Power Supply just for the xpector. To give you the best experience in Audio Quality. So you just concentrate on your music and relax knowing that the signal flow is simply the purest you can get.

Cascading and Direct Monitoring

The next step, once you have connected multiple xpector, is for each musician to individually mix their own instrument or voice into a mix. This is also fast and easy to implement.

We have designed the Direct Input exactly for this application. If you use an external preamp such as the skulpter or connect a DI input, the signal can be mixed into a shared band mix that the musicians share. Most of the time you want to hear your own instrument or voice more clearly, so use the direct controller to adapt the musician’s own signal to their listening habits.

With this application, recording sessions with more than one musician are no longer a problem.

Everything is latency-free for the best performance.



Just Technical Details.

Frequency response:                                     <10 Hz – 400 kHz (-3,0 dB)

Level:

Input:                                                                +22 dBu

XLR Outputs:                                                     +22 dBu

Impedance:

Input:                                                                 45 kOhm

Output:                                                              0,09 Ohm

Max output power:

@22 Ω :                                                            2 x 150 mW (RMS)

@600 Ω:                                                           2 x 150 mW (RMS)

Dimensions  (W x H x D, incl. Knobs):             4,1” x 5,39“ x 8,4“

                                                                        104 mm x 137 mm x 212 mm

Weight:                                                           3,17 lbs / 1,46 kg

Power consumption:                                      9 Watts
