Smooth, effortless highs.
Profile-optimized Midrange Driver
Clear mids and excellent directivity all the way to the top of the frequency response.
Powerful Woofer
Clean, punchy bass that doesn’t disrupt the mids and highs.
We know. We keep harping on about the “hyper-realistic” imaging of the IN-Series. What does that mean?
When you listen to a stereo set of speakers, you’re hearing information about where instruments and players were placed when the material was recorded. Even with purely digital material, producers can manipulate physical locations of elements in the mix, and you will hear these on a stereo recording.
Not only does this allow producers to create interesting spatial effects, but it means that you can work faster and with more confidence. An accurate soundstage lets you “see” each element of the mix in front of you, so you can hear exactly what happens when you make changes.
2-way systems with good waveguides, like Kali’s LP-6 and LP-8, do a good job at conveying this spatial information. However, because the tweeter and woofer on those speakers (and most studio monitors!) are separate, this information gets lost in the space immediately above and below the speaker. This means that at the listening position, you’re not hearing the full stereo picture.
The IN-Series solves this problem. The tweeter and midrange share an acoustic center, and the woofer is crossed over at a low-mid frequency, so the distance between the woofer and midrange is well under a quarter wavelength at the crossover point. This means that each IN-Series monitor is acoustically a point source. As such, it has the same excellent directivity that the LP-6 and LP-8 have at their sides in a full 360 degrees around the speaker. You’re hearing all of the spatial information at the listening position, so the soundstage that you hear will have every detail that’s present in the mix.
The IN-Series monitors have very low distortion. This is the result of unburdening both the woofer and the tweeter, so that both are doing less work; the tweeter is only focused on high frequencies, and the woofer only has to worry about bass.
Taking up the space in between in the hero of the IN-Series: the 4-Inch, profile-optimized midrange driver. This driver has a lot of work to do. In addition to reproducing midrange frequencies, it also acts as the waveguide for the tweeter. This means that the shape needed to be precisely engineered to provide an ideal dispersion characteristic for the tweeter.
It also means that the midrange needs to stay still. In many other co-axial or concentric systems, high excursion from the larger driver causes intermodulation distortion, and degrades the accuracy of the system. The midrange on the IN-Series is limited to less than 1 millimeter peak-to-peak excursion, making it acoustically stationary while still providing midrange to keep up with the powerful woofer and tweeter.
The new 2nd Wave in IN-8 and IN-5 features the latest technology developed by Kali. A new amplifier platform realizes a 12 dB reduction in self noise vs. the original IN-8, lower distortion, higher output, and better reliability.
Immersive
Kali’s IN-Series are an ideal solution for immersive mixing applications like Dolby Atmos. The coaxial architecture of the midrange and tweeter makes them an acoustic point source, allowing for hyper-realistic imaging in the 3-D soundfield. Importantly, Kali’s users enjoy excellent translation across a variety of systems, so when you’re mixing a high profile project, you know your client will be happy and the mix will sound its best.
Ceiling/Wall Mounting
Kali Audio’s speakers can be easily mounted for overhead use, or even to a wall, using Triad-Orbit and Triad-Orbit Precision products. Per-loudspeaker mounting plates are available for the LP-6 V2, IN-5, and IN-8 V2. Also available are mounts that interface with these mounting plates and Triad-Orbit’s wall mounting ecosystem of products. Before mounting a Kali loudspeaker, check to make sure that it says “Wall/Ceiling Mountable” on the back of the speaker. Contact Kali customer service if you have any questions. Your dealer can help you find the right TriadOrbit mounts for your application, and Kali is also here to help!
