Milab VIP-60 - Multi-Pattern Large Membrane Condenser Microphone

Milab VIP-60 - Multi-Pattern Large Membrane Condenser Microphone

37 years after the introduction of its predecessor, the brand new VIP-60 boasts an updated capsule and optimized circuitry to bring the sound of the classic VIP-50 into the 21st century.

How do you reinvigorate an iconic microphone without losing the “magic” in the process?

The Milab R&D team used a careful and meticulous approach which included an 18-month testing period with feedback from a number of highly skilled engineers in Sweden, Germany, the UK and the US. The result is a microphone with a superior performance when compared to its predecessor – most notably a significant reduction in self-noise – but fans of the VIP-50 will still recognize the unique sound with its ribbon-like warmth and sparkly highs – and, of course, the extremely smooth off-axis response.

Features

• Five selectable polar patterns
• 10/20 dB attenuation pads
• 200/500 Hz high pass filters
• Milab 2900 rectangular capsule
• Gold plated XLR connector
• Nextel® coating
• Customized SKB 3i Case

Specifications

• Product name

  Milab VIP-60

• Type

  Condenser

• Article number

  1160

• Frequency response

  20 to 20,000 Hz

• Polar pattern

  Cardioid, Wide Cardioid, Hypercardioid, Omni, Bidirectional

• Filters

  200 Hz & 500 Hz (switchable)

• Pre-attenuation pad

  -10 dB & -20 dB (switchable)

• Max. SPL (1 % THD at 1 kHz)

  118 dB

• Max SPL with 10 dB pad

  128 dB

• Max SPL with 20 dB pad

  138 dB

• Sensitivity at 1 kHz

  14 mV/Pa (± 1 dB)

• A-weighted noise level (IEC 179-A)

  14 dB

• Power supply

  48 ± 4 V Phantom (DIN/IEC)

• Current consumption

  4 mA

• Output impedance

  <200 Ω

• Minimum load impedance

  1 kΩ

• Connection

  3-pin XLR

• Length

  170 mm

• Width

  47 mm

• Depth

  50 mm

• Net weight

  400 g
