Overview
The Trinnov D-MON is a professional-grade monitoring controller with Trinnov’s Optimizer Room Correction technology, designed for studios working in stereo, 5.1, 7.1, and Dolby Atmos configurations (up to 9.3.6). It offers seamless EUCON integration for Avid Pro Tools users and provides a fully modular, software-upgradable system with flexible monitoring control.
Key Features
-
Room Correction: Built-in Trinnov Optimizer technology ensures accurate monitoring.
-
Dolby Atmos Support: Scales up to 18 channels.
-
Flexible Connectivity: Supports analog, digital, and networked audio workflows.
-
Zero-Latency Switching: Matrix and summing capabilities for efficient routing.
-
EUCON Integration: Works seamlessly with Avid Pro Tools.
-
Modular and Upgradable: Start with fewer channels and expand as needed.
Specifications
Digital Audio Connectivity
-
AES3 Inputs/Outputs (DB25, Tascam Pinout): 16 channels
-
Word Clock: 1x Input, 1x Output (BNC)
Analog Audio Connectivity
-
Balanced Inputs (DB25): 8
-
Balanced Outputs (DB25): 16
-
Balanced Outputs (XLR): 8
Multi-Purpose I/O (DB25)
-
General Purpose Control Inputs: 2
-
General Purpose Control Outputs: 1
-
Talkback / Listen Back Inputs: Balanced, 36V Phantom Power
-
Headphones Output: 1 (Unbalanced)
-
MIDI: 1x Input, 1x Output
Switching & Summing
-
Sources: 8 Cues / Talkback / Listen Back
-
Monitor Selection: Programmable Presets & Profiles
-
Routing: Any input, bus, or Optimizer output to any physical output
-
Summing: 18 inputs to 16 buses
Audio Processing
-
Native Resolution: Up to 12 channels at 96 kHz; above 12 channels at 48 kHz
-
Per Channel Adjustments: 31-band EQ, FIR EQ, gain, polarity, and delay
-
Delay Settings: Adjustable in meters, milliseconds, or frames
Audio Performance
-
ADC/DAC Resolution: 24-bit / 96 kHz
-
A/D Signal-to-Noise Ratio: 119 dB (A-Weighted)
-
D/A Signal-to-Noise Ratio: 118 dB (A-Weighted)
-
Processing Rate: Up to 96 kHz, 64-bit floating point
-
Clock Jitter Attenuation: >50 dB above 100 Hz
Power Supply
-
Voltage: 240V / 110V, 50/60 Hz (Manual Switch)
-
Power Consumption: 60W
-
Analog Section PSU: Linear PSU with toroidal transformer
-
Digital Section PSU: Switch-mode PSU
Dimensions & Weight
-
Unit Dimensions (W x H x D): 444 x 89 x 405 mm (17.5" x 3.5" x 16")
-
Shipping Dimensions: 68 x 56 x 21 cm
-
Weight: 9.6 kg (21.1 lbs)
-
Rack Mounting: 2U, fixed rack ears
Warranty
Conclusion
The Trinnov D-MON is a powerful, scalable, and future-proof monitoring controller built for high-end studio applications. Its room correction, extensive I/O, and Dolby Atmos support make it an ideal solution for professional engineers looking to optimize their mixing and mastering workflow.
